TECHNICAL SPECIFICATIONS
Bosch Performance E-Bike Motor
Sporty riding feel
The efficient and versatile drive system accelerates dynamically, reducing pedaling resistance and offering an authentic riding experience even without assistance.
Powerful right from the start
The motor accelerates dynamically and sportily even at low pedaling frequencies – for powerful assistance from the very first pedal stroke.
Built to last
Meets the highest requirements for trekking and eMTB. Precise motor control also reduces wear.
Perfect interaction
The multi-sensor concept and fast information processing ensure optimal interaction between you and your eBike.
Quiet ride
The noise-optimized transmission makes the Performance Line (25 km/h) one of the quietest in its class.
For every adventure
The eMTB mode for eMountainbikes allows for controlled and comfortable acceleration even off-road.
Lightweight and compact
A new motor concept reduces weight and size. Not only do you ride in style, you also enjoy agile handling. The Performance Speed Drive Unit weighs just 2.9 kg.
Power for long distances
Get to your destination faster: the Performance Line Speed version accelerates quickly thanks to a powerful motor with torque of up to 75 Nm.
Torque 65 Nm
For sporty acceleration even at high pedaling frequencies.
Max. assistance 275
Dynamic, ideal for long, sporty tours.
Max. speed 25 km/h
For every need up to 25 km/h.
Bosch Intuvia e-bike display
Maximum ease of use
Easy to use thanks to the separate control unit.
Perfect for commuters
Even when removed from the bike, it shows all important information, such as total mileage.
Excellent readability
Visible in all light conditions, even in direct sunlight.
Charging station
Intuvia charges your smartphone via a USB port.
Maintenance reminder
The optional reminder indicates when the next maintenance is due at your dealer.
Lighting system
When switched on, the lights automatically reactivate when the bike is started.
Push assist
Support up to 6 km/h. Two-stage activation for added safety.
Riding modes
- Turbo: powerful and direct assistance even at high frequencies.
- Sport/eMTB: versatile, sporty or urban assistance.
- Tour: constant support for long journeys.
- Eco: maximum efficiency and range.
- Off: no assistance, but all functions available.
FRAME
- Frame: 6061 aluminum
- Fork: SR Suntour NEX E25-HLO Lockout, steel spring, 50 mm travel, 1 1/8“ – 1 1/2” tapered steerer tube
- Headset: A-Head Tapered
EQUIPMENT
- Handlebar: Ergobar, oversize 640 mm
- Grips: XLC Comfort bo3
- Stem: Aluminum, adjustable angle, Ø 31.8 mm
- Saddle: Selle Royal Viento
- Seat post: Suspension, Ø 31.6 mm, aluminum
- Pedals: VP E461 aluminum, with reflectors
- Lights: Busch & Müller Upp, 30 lux / AXA Blueline
- Dynamo: Powered by system battery
- Luggage rack: Racktime Tria, SnapIt
- Mudguards: RPZ Evo, chromoplastic
- Kickstand: Ursus Mooi, adjustable
DRIVETRAIN
- Rear derailleur: Shimano Deore T6000, 10 speeds
- Gear shift: Shimano Deore T6000, Rapidfire
- Rear sprocket: Shimano HG50, 11-36 teeth
- Chain: KMC e10S
- Crankset: Samox, 38 teeth
- Chain guard: Horn Chain 18
E-BIKE SYSTEM
- Motor: Bosch Performance Line, 250W, 65Nm, 25km/h
- Display: Bosch Intuvia
- Battery: Bosch PowerPack (500 Wh)
- Charger: Bosch Standard Charger 4A
WHEELS
- Tires: Schwalbe Delta Cruiser Plus, 47-622 / 47-559, puncture resistant
- Rims: Ryde Zac421, double wall, aluminum
- Front/rear hub: Aluminum
- Spokes: Sapim Leader, black
BRAKES
- Brake levers: Shimano MT401-3, aluminum
- Brakes: Shimano MT400, aluminum, 180mm / 160mm
ADDITIONAL
- Maximum authorized weight: 130 kg
- Bike type: Trekking e-bike
- Display: Bosch Intuvia
- User: Men
- Motor: Bosch Performance
- Battery capacity: 500 Wh
- Model year: 2020
